Capabilities

Steelscape’s capabilities are built around continuous coil coating, advanced paint lines, and value‑added processing. Operating from facilities in Kalama, Washington and Rancho Cucamonga, California, we produce coated and painted light‑gauge steel and aluminum with a focus on consistency, precision, and downstream performance.

Precision in  Every Coil

Each capability supports reliable manufacturing, predictable results, and the demands of applications that rely on steel starting at the coil level. From tightly controlled coating application and color consistency to efficient processing and dependable product quality, our capabilities help customers improve manufacturing efficiency, reduce variability, and deliver consistent performance in the finished product.

Explore more in-depth and detailed information about Steelscape products and services by downloading the comprehensive Single-Bill Service Offer Manual.

Primary Capabilities

Metallic Coating

Painting Coil

We add aesthetic appeal and finish performance through paints, finishes, and textures applied on continuous paint lines. Steel may be painted after metallic coating, and aluminum is processed through the paint line to achieve consistent visual quality and coating performance.

ZINCALUME® steel is a formulation of aluminum‑zinc alloy metallic coating selected to support enhanced corrosion resistance and cut‑edge protection.

Also known by the trade name Galvalume®, this metallic coating can be readily formed into a variety of product shapes. ZINCALUME is manufactured at our Rancho Cucamonga, CA facility and is available as a bare product, featuring a uniform spangled surface, or can be painted in an endless array of colors.

The matrix below outlines Steelscape’s ZINCALUME Steel production capabilities.

Heading #1	Heading #2
* ZINCALUME Plus max output weight 20,000 lbs horizontal and 15,000 lbs vertical. Width restrictions may apply to less than 0.0157” total coated thickness. 0.0300″ thickness and greater is considered non-surface critical for some product grades and end-uses, both bare and painted. Inquire with a Steelscape Sales Representative for additional information. * For widths outside of this range. Inquire with a Steelscape Sales Representative. **** For heavier coating weights, inquire with a Steelscape Sales Representative.
Maximum Input Coil Weight	55,000 #
Maximum Output Coil Weight	38,000 #*
Thickness	0.012″ – 0.0356″**
Width	28″ – 50″***
Coatings	ZINCALUME®/Resin/Oil/ Passivant (Standard or RoHS Compliant)
Entry OD/ID	79″ max/20″ +/- 0.25″
Delivery OD/ID	76″ max/20″ +/- 0.25″
Cores	Not Available
Coatings	AZ35, AZ50, AZ55, AZ60**

Steelscape can evaluate requests for ZINCALUME Steel products that are not shown on the capability matrix above. Steelscape will evaluate these requests based on equipment capabilities and hot band supply. To inquire, please submit your request through ‘Ask Steelscape’.

ZINCALUME Steel Resources:

Explore more in-depth and detailed information about Steelscape products and services by downloading the comprehensive Single-Bill Service Offer Manual.

TruZinc® steel is hot‑dipped galvanized steel designed to provide proven corrosion protection and broad formability for downstream manufacturing.

This metallic coating can be readily formed into a variety of product shapes. TruZinc is manufactured at our Kalama, WA facility and is available as a bare product, featuring a uniform minimal spangled surface, or can be painted in an endless array of colors.

The matrix below outlines Steelscape’s TruZinc Steel production capabilities.

Heading #1	Heading #2
^ 0.300″ thickness and greater is considered non-surface critical for some product grades and end-uses, both bare and painted. Inquire with a Steelscape Sales Representative for additional information. * Resin coated products may have a different max weight. Width restrictions may apply to less than .0130” tct material * Standard passivant is RoHS compliant **** Less than G60 is not recommended for paint line feed. For heavier coating weights, inquire with a Steelscape Sales Representative.
Maximum Input Coil Weight	56,000 #
Maximum Output Coil Weight	56,000 #
Thickness	0.0120″ – 0.0470″^
Width	28″ – 51″**
Coatings	TruZinc/Resin/Oil/Acrylic Single-Coat Paint/Passivant***
Entry OD/ID	79.5″ max/20″ +/- 0.5″
Delivery OD/ID	79.5″ max/20″ +/- 0.5″
Cores	Not Available
Coatings	G30, G40, G60, G90, G100, G115, G125****

Steelscape can evaluate requests for TruZinc® Steel products not shown in the capability matrix above. Steelscape will evaluate these requests based on equipment capabilities and hot band supply. To inquire, please submit your request through ‘Ask Steelscape’.

TruZinc Steel Resources:

EExplore more in-depth and detailed information about Steelscape products and services by downloading the comprehensive Single-Bill Service Offer Manual.

TruZinc® Product Sheet PDF
TruZinc® Steel Grade Data Sheets PDF
TruZinc® Steel Processing Capabilities PDF
TruZinc® Steel SDS PDF
TruZinc® Plus Steel SDS PDF
TruZinc® Steel Technical Bulletin PDF
ZINCALUME® VS TruZinc® PDF

Steelscape’s paint lines apply and cure proven paint systems in a continuous coil coating process to support durability, color consistency, and finish performance. Coil is typically painted after metallic coating, while aluminum is processed through the paint line to ensure coated finish performance and appearance.

Steelscape offers a wide range of creative painted solutions, including decorative prints, low-gloss finishes, textures, and more. Our two full-service paint lines are strategically located in the Western U.S. near major transportation hubs for both truck and rail.

The matrix below outlines Steelscape’s pre-paint (coil coating) production capabilities.

Facility	Kalama	Rancho Cucamonga
* If vertical, skidded max weight is 15,000#. Refer to your Steelscape Sales Representative for minimum lineal footage restrictions on multiple pass orders and Steelscape branded paints. * Widths outside those listed may be possible depending on thickness, steel grade and post slitting if applicable. Inquire with your Steelscape Sales Representative. **** Requires additional processing to reverse wrap (slitter/embosser).
Maximum Entry Coil Weight	58,000 #	ZINCALUME® 38,000 #, TruZinc® 30,000 #, External supplied 20,000 #
Maximum Output Coil Weight*	33,000 #	20,000 #
Minimum Lineal Footage**	1,600 ft.	1,600 ft.
Thickness***	0.0115″ – 0.039″	Steel: 0.0130 – 0.0460″ Al: 0.0320″ – 0.0630″
Width***	26″ – 49.5″	28″ – 52″
Pretreatment	Chemetall 1500	Chemetall 1500
Substrates	TruZinc (galvanized), ZINCALUME (Galvalume®), Cold-Rolled	TruZinc (galvanized), ZINCALUME (Galvalume), Cold-Rolled, Aluminum, Stainless, TMBP, EG
Finish Coatings	Acrylic, Polyester, SMP Fluorocarbon, Plastisol	Acrylic, Polyester, SMP Fluorocarbon, Plastisol
Primer Coatings	Urethane, Epoxy, Polyester	Urethane, Epoxy, Polyester
Other Coatings	Resin/Passivant (standard or RoHS) by rare exception	Resin/Passivant (standard or RoHS) by rare exception
Entry OD/ID	81.5″ max/20″	79″/20″ or 24″ +/- 0.50″
Delivery OD/ID	72″ max/20″	64″ max/20″
Cores	Available	Available
Reverse Wrap	Available	Available****
Branding Ink	UV	UV
Branding Characters	275 Standard Text (Steelscape, KA_CPL, Date/Time)	250 Standard Text (Steelscape, RA_CPL, Date/Time)
Branding Size	½”	½” max
Branding Location	Bottom – 4″ in from edge	Bottom – 3.5″ in from front edge

Steelscape can evaluate requests that are not shown on the capability matrix above. Steelscape will evaluate these requests based on equipment capabilities and hot band supply. To inquire, please submit your request through ‘Ask Steelscape’.

Paint Line Resources:

Explore more in-depth and detailed information about Steelscape products and services by downloading the comprehensive Single-Bill Service Offer Manual.

Pre-Painted Steel Processing Capabilities PDF
Pre-Painted TruZinc® Steel SDS PDF
Pre-Painted Zincalume Steel SDS PDF
Pre-Painted Technical Bulletin PDF

After painting, coils are either packaged for shipment or enhanced through value-added processing based on customer requirements, including slitting, embossing, or cut-to-length. These services are designed to reduce downstream handling and align material with customer equipment, specifications, and end-use needs.

Cut-to-Length

Steelscape’s cut‑to‑length capability in Kalama, WA converts coil into flat sheets cut to specified dimensions for applications requiring sheet processing.

Heading #1	Heading #2
* Maximum thickness is limited for fluorocarbon paint systems due to concerns with scratching the top surface upon stacking. Inquire with your Steelscape representative for painted products greater than 0.0236″ ordered thickness. ** Standard width is 48″; it can be made available in any width up to 60″.
Maximum Entry Coil Weight	60,000 #
Thickness (T)	0.010″ – 0.050″ Bare* 0.0101 – 0.030″ Painted*
Width	12″ – 60″
Maximum Pallet Weight	15,000 #
Minimum Cut Length	36″
Maximum Cut Length	120″ (up to 150″ – trial only)
Entry OD/ID	84″/20″ +/- 0.5″
Minimum Stack Height	24″ with skid
Strippable Film**	48″ (-0.25″/+0.375″)

Slitting

Steelscape’s slitter lines in Kalama, WA, and Rancho Cucamonga, CA, reduce master coils to multiple widths to customer specifications, with parameters varying by facility and substrate.

Facility	Kalama	Ranch Cucamonga
* If vertical, skidded maximum weight is 12,500#. For smaller widths inquire with your Steelscape Representative. * OD max depends on number of mults and crown in the coil. **** Cores are “all or nothing” for the whole arm of mults (i.e. if one mult on the arm is less than 10″, then none of the mults on the arm can have cores). Please inquire for cores < 10″ due to safety issues.
Maximum Entry Coil Weight	55,000 #	20,000 #
Maximum Delivery Weight	55,000 #	20,000 #
Thickness (T)	0.010″ – 0.050″	0.011″ – 0.046″ Steel 0.032″ – 0.063″ Aluminum
Width	16″ – 52″	12″ – 52″
Maximum Number Mults	24	20 if .025″ < T<.050″ 40 if T<.025″
Maximum # sizes per setup	Depends on knives & size of mults	Depends on knives & size of mults
Minimum Slit Width (W)**	2.00″	4.00″
Entry OD/ID***	79″ max/20″	64″ max/20″
Delivery OD/ID	79″ max/20″	64″ max/20″
Cores****	W > 10″, T < 0.030″	W > 10″
Minimum Slit Drop	0.375″	0.375″

Embossing

Steelscape offers non directional stucco embossing from our Rancho Cucamonga, CA facility to add texture and depth to steel and aluminum for functional and aesthetic applications. The embossing offer includes substrate and gauge dependent limitations and packaging requirements to protect embossed surfaces.

Heading #1	Heading #2
* If outside of this thickness and wider than 48.5″, inquire with your Steelscape Representative. Grade/hardness restrictions may apply to some substrates. Cannot process Grade 80 steel. Grade 50 above 0.0236″, inquire with your Steelscape Representative. * Embossed material will collapse if packaged longitudinally.
Pattern	Non-Directional Stucco
Maximum Entry Coil Wt	30,000 #
Maximum Output Coil Wt	12,500 #
Thickness	0.0180″ – 0.0296″* Steel 0.0320″ – 0.040″ Aluminum
Width	23.937″ – 48.5″ Steel 18″ – 48.5″ Aluminum
Depth	. 007″ up to .01″ thick
Substrates	TruZinc (HDG), ZINCALUME (Galvalume), CRS, ALUM**
Entry OD/ID	20″
Delivery OD/ID	OD 64″/ID 20″
Cores	Required
Reverse Wrap	Available
Vertical Only***	Delivery OD/ID

Steelscape offers a range of packaging options designed to protect coated steel and aluminum throughout handling, transportation, and storage. Our packaging approaches are selected to support material integrity, safety, and downstream manufacturing requirements.

The most requested packaging configurations are listed below as part of our Standard Packaging Offer.

Standard Packaging – General Descriptions

Horizontal, Tow Eye Bands
Horizontal, Paper Wrap, Two Eye Bands
Horizontal, Plastic (VCI) Wrap, Two Eye Bands, ID and OD Protection, Core. For painted only. Required for Rail Gondola
Vertical, Plastic (VCI) Wrap, Skid, Core
Vertical, Plastic (VCI) Wrap, Skid
Side Loaded Skit – Cut-to-Length
Vertical, Wrap, Skid, Rubber Mat, Boxcar (3-run 4×4)
Vertical, Exhibit Wrap, Skid, Rubber Mat, Boxcar (3-run 4×6)

Non‑standard packaging requests may be considered on an inquiry basis and may be subject to additional charges. Packaging availability and wrap types can vary by facility, so customers should consult with a Steelscape Sales Representative to confirm the most appropriate option for their material and shipping needs.
